Heat Exchanger Repair and Inspection in Salt Lake County

The heat exchanger is the single component in a gas furnace that separates two air streams that must never mix: the combustion side (containing carbon monoxide, carbon dioxide, water vapor, and other combustion products) and the supply air side (the conditioned air circulated through your home’s duct system). When the heat exchanger develops cracks, perforations, or rust-through failures, combustion gases can pass from one side to the other and enter the air your family breathes. Carbon monoxide is the specific concern — colorless, odorless, and capable of causing illness or death depending on exposure level. Heat exchanger integrity isn’t an HVAC issue. It’s a safety issue.

This is also a service category where the industry has a credibility problem. Some contractors condemn perfectly good heat exchangers to drive furnace replacement sales. Other contractors miss genuine heat exchanger failures because they don’t perform the combustion analysis or visual inspection required to detect them. We approach heat exchanger work with both diagnostic rigor and a clear bright line: we don’t condemn equipment that’s actually fine, and we don’t operate equipment with confirmed cracks regardless of customer preference or financial considerations. The diagnostic process below is how we determine which side of that line a given furnace falls on.

---

What a Heat Exchanger Does

In a forced-air gas furnace, the heat exchanger is a sealed metal structure (usually aluminized steel or stainless steel for modern equipment) with two completely separated paths:

• The combustion side — gas burns inside passages that direct combustion gases through the heat exchanger and out the flue. These passages are sealed from the rest of the system.
• The supply air side — the blower pushes return air over the outside surfaces of the heat exchanger. Heat transfers from the hot combustion-side metal to the air being moved through the duct system.

The two air streams never touch. As long as the heat exchanger is intact, only heat moves between them. If the heat exchanger develops a crack, perforation, or rust-through failure, the seal between the two sides breaks down. Under operating conditions, the blower can pull combustion gases through the breach into the supply air stream, distributing them throughout the home.

How Heat Exchangers Fail

Heat exchanger failures don’t happen overnight. They develop over years of thermal cycling stress, corrosion, and operational wear. Common failure mechanisms:

Thermal Fatigue Cracking

Every time a furnace cycles on, the heat exchanger metal heats rapidly. When it cycles off, it cools. Each thermal cycle expands and contracts the metal slightly. Over thousands of cycles, microscopic stress accumulates in the metal — particularly at bends, welds, and stress concentrators. Eventually, hairline cracks develop. The cracks grow with continued cycling until they become large enough to allow gas migration.

Thermal fatigue is the most common heat exchanger failure mode on furnaces 12–20 years old. Furnaces that short-cycle (oversized equipment, equipment with restricted airflow, equipment with thermostat issues) accumulate cycles faster and reach thermal fatigue failure sooner — sometimes at 8–10 years.

Corrosion

Combustion produces water vapor as a byproduct. In high-efficiency condensing furnaces, this water vapor is intentionally condensed inside a secondary heat exchanger to extract additional heat — and the condensate is mildly acidic. In non-condensing furnaces, water vapor should remain gaseous and exit through the flue, but if the furnace runs too cool (oversized equipment, undersized return air causing short cycles), water can condense inside the primary heat exchanger where it doesn’t belong. Acidic condensate corrodes aluminized steel from the inside out, eventually creating perforations.

Corrosion failures are particularly common on 80% AFUE atmospheric-vent furnaces that have been operating outside their design conditions (oversized, short-cycling, low return air) for extended periods. The corrosion is internal and often invisible from the cabinet exterior until failure has progressed significantly.

Mechanical Damage

Less common but possible: physical damage to the heat exchanger from improper service work (a sheet metal screw driven into the heat exchanger during cabinet reassembly, a service tool slipping during repair), debris that entered through inadequate combustion air supply, or foreign objects falling into the heat exchanger through the flue.

Rust-Through from Water Damage

Furnaces in basements that have flooded, or furnaces with leaking humidifiers above them, or furnaces with condensate drain failures, can suffer water damage to the heat exchanger. Rust forms from outside the heat exchanger rather than from inside, eventually creating perforations through the metal.

Symptoms of a Cracked Heat Exchanger

The hardest part of heat exchanger diagnostics is that many failures produce no obvious symptoms to the homeowner. The combustion gas migration into the supply air may be subtle enough that the family doesn’t notice anything wrong until it shows up on a combustion analysis or a CO detector activation. That said, several indicators should prompt investigation:

• CO detector activation in the home — particularly during heating operation. Even a single transient alarm warrants investigation.
• Soot accumulation around the furnace or in burner area — indicates combustion problems that often accompany heat exchanger issues
• Rust accumulation visible through inspection ports or in the burner area
• Flame disturbance when the blower starts — the burner flames physically deflect or flutter when the blower kicks on. This indicates pressure changes inside the heat exchanger that can occur with cracks.
• Family members reporting flu-like symptoms (headache, nausea, dizziness, fatigue, confusion) that improve when away from home. These symptoms can be early-stage CO exposure.
• Strong “chemical” or “burning” smells from the supply registers during furnace operation
• Yellow flames at the burners instead of clean blue flames — indicates combustion problems that can accompany heat exchanger issues
• Combustion analysis showing elevated CO in the supply air stream — direct evidence of heat exchanger migration

Any of these symptoms — particularly CO detector activation — warrant immediate professional inspection. If your CO detector is sounding, leave the home, ventilate by opening doors and windows, and call us or your local fire department before re-entering for extended periods.

How We Diagnose Heat Exchanger Problems

Heat exchanger diagnostics require multiple complementary methods. No single test confirms a crack with absolute certainty, so we use several approaches and weigh the evidence.

1. Combustion Analysis

The most sensitive diagnostic for heat exchanger problems. We measure CO at multiple points and operating conditions:

• CO in the flue gas at high-fire steady state — baseline reading for combustion quality
• CO in the supply air stream — any reading above ambient is a red flag
• CO trend as the blower cycles on and off — heat exchanger cracks often produce CO spikes when the blower starts because pressure differential pulls combustion gases through the crack
• Ambient CO in the mechanical room — elevated readings suggest combustion gas leakage
• CO ppm in living spaces if mechanical-room readings raise concerns

Combustion analysis equipment ($800–$2,000 in instrumentation) is what separates rigorous heat exchanger diagnostics from guessing. Most contractors don’t own combustion analyzers; some who own them don’t use them on routine service calls.

2. Visual Inspection

With the furnace running, we inspect the heat exchanger through whatever access ports the equipment provides:

• Burner area inspection with mirror and flashlight — looking for visible cracks, holes, rust accumulation, flame patterns disturbed by airflow from the supply side
• Heat exchanger exterior surfaces from the blower compartment — looking for rust-through, visible cracks, water damage indicators
• Borescope inspection through inspection ports or accessible openings — provides magnified view of heat exchanger interior surfaces. Borescope inspection finds cracks that aren’t visible to direct inspection.

Visual inspection has limits — many heat exchanger surfaces aren’t accessible to direct view even with borescope, and small cracks can be obscured by rust scale. But visible cracks and rust-through failures provide definitive evidence when they’re observable.

3. Flame Disturbance Test

With the furnace burners firing, we observe the flame pattern while cycling the blower. In a sound heat exchanger, the flames remain steady when the blower starts because the heat exchanger isolates the burner air from the supply air. With a cracked heat exchanger, the flames physically move or flutter when blower airflow changes pressure inside the heat exchanger. This is one of the most reliable in-the-field diagnostic indicators of a cracked heat exchanger.

4. Isolation Pressure Testing (When Indicated)

For furnaces where combustion analysis and visual inspection suggest possible heat exchanger issues without confirming them, we can pressure-test the heat exchanger by sealing the flue connection, plugging the burner inlet, and pressurizing the combustion side with low-pressure air. A pressure decay over time indicates a breach in the heat exchanger seal. This is the most definitive in-the-field heat exchanger test but requires furnace shutdown and access work, so we typically reserve it for borderline diagnoses.

5. CO Pattern Analysis

If we suspect heat exchanger issues but the initial diagnostic isn’t conclusive, we can leave a continuous-monitoring CO detector in the home for several days to capture CO patterns during different operating conditions. CO spikes that correlate with furnace operation strongly suggest heat exchanger migration even when single-point measurements appear normal.

What Happens If We Find a Crack

A confirmed cracked heat exchanger is a safety issue, not a comfort issue. Our response when we confirm a crack:

1. We document the finding with combustion analysis printouts, photos where possible, and a written safety notification.
2. We recommend immediate furnace shutdown until repair or replacement is completed. Continuing to operate a furnace with a confirmed cracked heat exchanger isn’t safe — even if symptoms haven’t appeared yet, CO migration can vary day-to-day with operating conditions.
3. We discuss repair vs. replacement options based on equipment age, warranty status, and your specific situation:
   • Under-warranty heat exchanger: Many manufacturers warrant heat exchangers for 20 years or lifetime when properly registered. If the part is under warranty, replacement is typically the right answer — manufacturer provides the part, you pay labor only ($800–$1,800 typical).
   • Out-of-warranty heat exchanger, furnace under 12 years old: Heat exchanger replacement out-of-warranty typically runs $1,400–$2,500. Sometimes worth it; often the better economic answer is full furnace replacement.
   • Out-of-warranty heat exchanger, furnace over 15 years old: Full furnace replacement is almost always the right answer. Heat exchanger replacement on an aging furnace postpones the inevitable and doesn’t deliver the efficiency or reliability gains of new equipment.
4. We provide temporary alternatives while replacement is arranged — portable electric heaters for short-term use, scheduling priority for furnace replacement, and CO monitoring if the home will be occupied during the transition period.
5. We never recommend continued operation regardless of customer preference. Some homeowners ask “can we just run it until I can get a new furnace?” — we don’t do that. The risk profile of operating a furnace with a confirmed cracked heat exchanger is unacceptable, and we won’t put our company name on advice that could harm a family.

Why Some Contractors Misdiagnose Heat Exchangers

The industry has well-documented credibility problems on heat exchanger diagnostics. Two failure modes are common:

False Positives (Condemning Healthy Equipment)

Some contractors condemn heat exchangers based on insufficient diagnostic evidence — superficial rust visible from the cabinet exterior, flame patterns that fall within normal range, age alone, or claims of “cracks I can see” without showing the customer specific photos or measurements. This is sometimes accidental (the technician genuinely believes they see a crack and isn’t trained to diagnose properly) and sometimes deliberate (creating a safety scare to drive furnace replacement sales).

If you’ve been told your heat exchanger is cracked but you’re not confident in the diagnosis, get a second opinion. We perform heat exchanger inspections as a standalone service ($175–$275) with combustion analysis, borescope inspection, and flame disturbance test, and we’ll provide written documentation of findings either way.

False Negatives (Missing Genuine Failures)

Some contractors miss genuine heat exchanger failures because they don’t perform the diagnostic work required to find them. A visual look-over from the front of the furnace cabinet often misses cracks that are obvious with proper combustion analysis and borescope inspection. Customers in homes with cracked heat exchangers continue running their furnaces — sometimes for months or years — because their service contractor said “looks fine to me.”

This is why combustion analysis matters on every furnace service call. Numbers don’t lie; visual judgment can. Elevated CO patterns flag heat exchanger issues even when the visual inspection appears normal.

Heat Exchanger Replacement Process

When heat exchanger replacement is the right answer (typically only on under-warranty equipment where the part is covered), the work involves:

1. Order replacement heat exchanger from manufacturer under warranty. Typical lead time 3–10 days. We file the warranty claim on your behalf.
2. Schedule the install. Most heat exchanger replacements take 4–8 hours on-site depending on furnace model and access.
3. Disassemble the furnace to access the heat exchanger — typically requires removing burner assembly, gas valve, blower assembly, and various sheet metal panels.
4. Remove old heat exchanger and inspect surrounding components (burner condition, combustion air supply, venting integrity, blower wheel condition).
5. Install new heat exchanger with new gaskets, properly torqued fasteners per manufacturer specification.
6. Reassemble furnace with all components properly reconnected and verified for gas-tight and air-tight seals.
7. Re-commission the furnace with full combustion analysis, gas pressure verification, draft check, temperature rise measurement, and ambient CO testing.
8. Document the replacement with measurements, photos, and updated warranty registration.

Heat Exchanger Inspection and Repair Costs

• Standalone heat exchanger inspection (combustion analysis, visual inspection, borescope inspection, flame disturbance test, written findings): $175–$275
• Heat exchanger inspection included in furnace tune-up: Standard, no additional charge
• Isolation pressure test for borderline diagnoses: $250–$400 additional
• Continuous CO monitoring (multi-day measurement to capture operating patterns): $150–$300 depending on monitoring duration
• Warranty heat exchanger replacement (labor only, manufacturer provides part): $800–$1,800 depending on furnace model and labor access
• Out-of-warranty heat exchanger replacement (part + labor): $1,400–$2,500
• Full furnace replacement when heat exchanger failure triggers the decision: $4,500–$14,000 depending on equipment tier (see furnace installation page)

Manufacturer Warranty Coverage

Most major HVAC manufacturers provide extended warranties on heat exchangers when properly registered within 60–90 days of original installation:

• Trane: 20 years parts, lifetime on select premium equipment
• Carrier: 20 years parts on most equipment
• Lennox: Lifetime on most premium equipment, 20 years on standard equipment
• Goodman: Lifetime parts on most equipment
• Rheem: 20 years parts on most equipment
• Bryant: 20 years parts on most equipment

Labor for warranty replacement is NOT typically covered by standard warranties (typically $800–$1,800 out-of-pocket). Extended manufacturer warranties purchased at original installation (typically $400–$1,200 added to the project price) can extend labor coverage for the same period.

Maintenance record requirements: most warranties require documented annual professional maintenance to remain valid. Customers without records may have warranty claims denied; customers with documented annual tune-ups get claims paid. We keep maintenance records on every Aegis customer in our system.

Carbon Monoxide Safety

Any home with combustion appliances — furnace, boiler, water heater, gas range, gas dryer — should have functioning carbon monoxide detectors on every level. CO detectors are not optional safety equipment in homes with gas appliances. Battery-powered or hardwired, replaced every 5–7 years per manufacturer specifications.

If your CO detector activates, treat it as an emergency:

1. Leave the home immediately and ventilate by opening doors and windows on your way out
2. Call 911 or your local fire department from outside the home if anyone has symptoms (headache, dizziness, nausea, confusion, drowsiness)
3. Don’t re-enter for extended periods until the source has been identified and corrected
4. Call Aegis at (385) 250-0687 for HVAC inspection. Cracked heat exchangers, venting failures, and combustion problems are common CO sources we can identify and address.

If you don’t have CO detectors or yours are past their service life, we strongly recommend immediate installation. CO detectors cost $20–$80 each — inexpensive insurance against a genuinely dangerous failure mode.

Frequently Asked Questions

How do I know if my heat exchanger is cracked?

The most reliable indicator is professional combustion analysis showing CO migration patterns, visible cracks on borescope inspection, or flame disturbance when the blower starts. Symptoms you can observe include CO detector activation, soot accumulation, rust visible through inspection ports, yellow burner flames, and family members reporting flu-like symptoms that improve away from home. Any of these warrant immediate professional inspection.

How much does heat exchanger replacement cost?

Warranty replacement (labor only, manufacturer provides the part) typically runs $800–$1,800. Out-of-warranty replacement (part + labor) typically runs $1,400–$2,500. Most furnaces 12+ years old with cracked heat exchangers are economically better-served by full furnace replacement at $4,500–$14,000 depending on equipment tier — heat exchanger replacement on aging equipment postpones the inevitable without delivering efficiency or reliability gains.

Is it safe to run my furnace if the technician says the heat exchanger might be cracked?

No. We don’t recommend operating a furnace with a confirmed or suspected cracked heat exchanger regardless of cost considerations or comfort needs. CO migration through cracks can vary day-to-day with operating conditions, so even if symptoms haven’t appeared yet, the risk is unacceptable. The right answers are repair (under warranty), replacement (out of warranty), or temporary alternatives (portable heating) while replacement is arranged.

Can a cracked heat exchanger be repaired or sealed?

No. Heat exchanger metal that has cracked from thermal fatigue, corrosion, or other failure modes can’t be welded, sealed, or patched in any way that’s safe for continued operation. The stresses that caused the crack are still present; any “repair” would fail again quickly, and combustion gas migration during the interim creates real CO risk. Any contractor offering to “patch” or “seal” a cracked heat exchanger is recommending something that isn’t safe and isn’t acceptable practice in this industry.

How long does a heat exchanger last?

Properly sized, installed, and maintained heat exchangers typically last 15–25 years in the Salt Lake climate. The valley’s inversion-driven extended heating seasons accumulate more operating hours and thermal cycles than less inversion-prone climates, which can shorten useful life. Heat exchangers on oversized equipment that short-cycles often fail at 8–12 years. Heat exchangers on properly sized equipment with good maintenance can last 25+ years.

Will a CO detector catch a cracked heat exchanger?

Sometimes, but not reliably. CO detectors are designed to alarm at concentrations that cause acute health effects (typically 70 ppm for extended periods or higher for shorter durations). Low-level CO leaks from heat exchanger cracks may produce levels that don’t trigger alarms but still cause chronic symptoms (headaches, fatigue, malaise) in occupants. CO detectors are essential safety equipment, but they don’t substitute for periodic professional combustion analysis on combustion appliances.

Do you provide second opinions on heat exchanger condemnations?

Yes. If you’ve been told your heat exchanger is cracked but you’re not confident in the diagnosis, we’ll perform a standalone heat exchanger inspection ($175–$275) with combustion analysis, visual inspection with borescope, and flame disturbance test, then provide written documentation of findings. If we agree with the original diagnosis, you have confirmation. If we disagree, you have evidence to push back on the original contractor’s recommendation. We’ve gone both directions on second opinions and always document findings honestly.

---
